ePowerControl SD / SD+
Solar-Diesel hybrid controllers
A solar-diesel hybrid controller created to safely, easily,
and quickly integrate solar plants with single (SD)
or
multiple diesel generators (SD+).
Why choose ePowerControl SD?
Ensured minimum genset loading
Adjust solar inverters power to prevent the genset from running at a low load, ensuring efficient and reliable performance.
Grid feed-in management
Curtail solar power to prevent leakage to the main grid, minimize wastage and maximize the utilization of PV energy on-site.
Power factor Improvement
Through the reactive power management of solar inverters, improve your power factor both in grid-tied and islanded configurations.
Reduced fuel consumption
Integrate PV + diesel system seamlessly to minimize fuel consumption.
Reclaim the control on the operation of your plant
Integrate PV + diesel system seamlessly to minimize fuel consumption. Regain autonomy on your site with easy setup and operation of your site, ensuring reduced LCOE.
How our solar diesel hybrid controller is working?
Ensure control with integrated features
Minimum genset loading
Control of solar inverters to respect minimum loading of gensets.
Export and Import control for a single or multiple points of injection
Management of solar inverters, genset controllers and breakers to limit export to the grid and import (peak shaving) from the grid in grid-tied configuration.
Reactive power management
Reactive power is controlled dynamically to regulate PF at
PCC or genset level within a
configured range. Includes
the possibility to prioritize
active or reactive power objectives.
Avoid fluctuations
Limitation of ramps for all controlled assets both for active and reactive power control.
Advanced maintenance and failsafe modes
Maintenance mode for assets to keep logging data from assets which should temporarily not be used for control. Optimized failsafes to stop devices when communication of key elements are missing.
Monitor your assets with data Intelligence
Reliable datalogging & data acquisition
from all linked devices on site (meters, solar inverters, genset controllers, weather stations (irradiance/t°), and I/O modules), & offer a secure local storage.
Data export & visualization
- Locally, over USB,
- Locally, over Modbus gateway
- Remotely, using ePowerMonitor or
compatible third-party monitoring platforms
(FTP push, API integration).
Unlock monitoring capability with our hypervision, platform ePowerMonitor
Elum has maximized the profitability of many hybrid power plants worldwide
Central Asia
C&I
200 kWp
Solar diesel integration on a chemical factory in Pakistan
ePowerControl SD optimizes solar usage and manages backup genset loading in a 200 kW grid-tied PV solar project for a chemical factory.
South Asia
C&I
140 kWp
Solar diesel integration of Rainforest resort in Igatpuri, India
ePowerControl SD optimizes solar integration and ensures seamless transition during grid fluctuations at an Indian rainforest resort.
LATAM
C&I
570 kWp
Solar diesel integration of an agricultural farm in São Paulo, Brazil
ePowerControl SD enabled efficient solar integration and reduced diesel usage in a 570 kWp grid-tied project for an agricultural farm in São Paulo.
SSA
C&I
360 kWp
Solar diesel integration of 5 Star Superspar mall in South Africa
ePowerControl SD project ensures stable power for a South African mall during load shedding.
Frequently asked questions
What are the applications for which the SD series are suited?
ePowerControl SD is suited for the control and monitoring of solar energy systems integrating PV plants and up to 4 gensets, grid-tied or off grid, with a maximum capacity of 300 kWp. For plants above this capacity, see our HFS product.
How does the PV / genset integration work?
The PV production is automatically adjusted so as to have a maximum PV penetration while ensuring the gensets do not run below the minimum loading value (typically average 30% of genset nominal capacity).
Does the SD include the zero export feature?
The zero export feature is included in all or our controllers. Our solar diesel hybrid controller curtails the right amount of solar power to enable a maximum PV production, while ensuring zero export to the grid, thus avoiding penalties from the grid operator.
Does the solution include reverse power protection function?
The controller includes the minimum genset loading feature which ensures a certain level of reverse power protection, but not entirely. It’s therefore important to install a Reverse power protection.
